Home > Products > Graphite Tube > PTFE Filled black/graphite tube/pipes for sealing

PTFE Filled black/graphite tube/pipes for sealing

  • PTFE Filled black/graphite tube/pipes for sealing
  • PTFE Filled black/graphite tube/pipes for sealing
  • PTFE Filled black/graphite tube/pipes for sealing
  • PTFE Filled black/graphite tube/pipes for sealing

PTFE Filled black/graphite tube/pipes for sealing

    Payment Type: L/C,T/T
    Terms of Trade: FOB,CFR,CIF,FCA
    Min. Order: 1 Piece/Pieces
    Delivery Time: 10 Days
    Packaging: Standard Export Package
    Productivity: 15 t
    Brand: Chunhuan
    Transportation: Ocean,Land,Air
    Place of Origin: Zhenjiang China
    Supply Ability: 15 t
    Certificate: ISO,REACH,ROHS,ASTM,FDA
    HS Code: 392099100000
    Port: Shanghai,Qingdao,Shenzheng

Basic Info

Model No.: molded and extruded

Product Description

PTFE Filled black/Graphite Tube/pipes


If you are in search of best quality (PTFE) Molded Rods, then we are the one-stop destination for you. Molded Rods are used in large number of industrial applications and are known for their durability and strength. We are tagged as one of the most illustrious PTFE Molded Rods Exporters from China.



There are three types of PTFE tube

01.Paste Extruded Tube

The tube is made by paste extruded with disperse rsin.

02.Plug Extruded Tube

The tube is made by plug extruded with suspension rsin.

03.Molded Tube

The tube is made by molded method.


SPECIFICATION OF PTFE TUBE

OD(mm) Wall Thickness(mm) Length(mm)
Paste Extruded Tube 0.5~25 0.1~2.5 According to customer's request
Plug Extruded Tube 25~250 1.5~8 According to customer's request
Molded Tube 25~2000 5~500 100~300

There are many specifications are in stock. There are too much data to list here.

And special specifications can be customized.

If you have any interest, please contact us. We will response to you as soon as possible.



Main features of PTFE sheet :

1. Temperature resistance ---It is able to work stably between -180°C to +260°C.

2. Excellent chemical corrosion resistance ---Applicable medium includes oil, acid solution and almost all chemical materials.

3. Excellent non-sticky property - --With low friction coefficient it easier to remove those resin, dopes, oil and other sticky things.

4. Anti-aging, weathering resistance.

5. Excellent insulation property.

6. Filled material: Filled PTFE products has more outstanding performance by adding filler such as carbon, graphite, bronze, glass fiber, carbon fiber, MOS2, PEEK, PI, POB BaSO4, SiO2, glass bead, polyamide.

TECHNICAL DATA SHEET OF PURE TUBE

Item ASTM Data Unit
Mechanical Properties
Density D792 2.1~ 2.2 g/m3
Tensile strength D638 ≥25 about 25 ~ 45 MPa
Elongation at break D638 ≥150 about 200~ 350 %
Compression strength D695 24 MPa
Shore D Hardness D636 50-60 -
Friction coefficient on steel 0.01 -
Thermal Properties
Working Temp -180 ~ 260 °C
Melting point 330 °C
Produce Max. Temp 390 °C
Fire Resistance UL94 V-0
Brittle point temperature -268 °C
Electrical properties
Dielectric strength D149 >1400 kV/mm
Volume resistivity D257 >1018 Ω·cm
Surface Resistivity D257 >1016 Ω
Dielectric constant D150 2.1
Conventional properties
Chemical solvent resistance Excellent
Water absorption (25℃ ) D570 0.01 24h/%
limit oxygen index D2963 >95

ABOUT OUR SERVICE

1)Your inquiry will be replied within 2 hours during working time,Within 24 hours when rest time.

2)Our working time is 7.30 AM --17:30 PM,Monday to Saturday.

3)General samples time can be arranged within 2--5 days.

4)Orders will be produced exactly as request and approved samples.

5)When mass production,we send photos to show the production line.And confirm the estimate time again.

6)At the end of mass production,photos and samples will send to you for approval.You can arrange the inspection.

7)Before shippment,our QC will have inspection to make sure the quality.

8)We always try best to ensure every order to delivery in time.


Payment Terms

1)T/T,Cash,L/C.

2)30% deposit,70% balance before ship.

3)Lead time: 15 days after received deposited for 2tons.

4)Delivery way: By sea,By air, By EMS,DHL,UPS,TNT,Fedex.

Packing & Delivery


For sample: By EMS,DHL,UPS,TNT,Fedex

around 5--7 working days to arrive

For Bulk order:

1.Qty of 2tons,within 15 days.

2.Via Sea

3.Delivery time:we will finish production in 15days for 2tons.

4.For 20 GP,may nee around 30 days.


PICTURES OF OUR PRODUCTS

ptfe tube rod




ZHENJIANG CHUNHUAN SEALING MATERIALS CO.,LTD(GROUP)

 Zhenjiang Chunhuan Sealing Materails Co.,Ltd,located in Yangzhong City,Jiangsu Province,China. It wa founded in 1985,now being a leading company in China after more than 32 years development.We have more than 200 employees in factory. We specialize in PTFE products,including PTFE Skived sheets,Molded sheets,PTFE rods,pipes,gaskets,packings and tubes,etc.We have passed ISO 9001,and also have ROHS,FDA,ASTM ,REACH certificates.Now our mainly market are all over the world,especially Korea,USA,Italy,Japan,Australia...... We are always ready to provide the high products,the best service,scientific management,resonable price and good culture of company.
